sn500X
Housing
No.
Shaft Dia
d1
Dimensions(mm) Hou-
sing
Wt
(kg)
Bearing
No.
Adapter Sleeve Locating Ring
mm in D
H8
a b c g
H12
h
h12
L L1 W n m s u v x d2
H12
d3
H12
f1
H13
f2 Number Q
T
Y
SN505 20 3/4 52 165 46 22 25 40 67 70 75 25 130 M12 15 20 22 21.5 31 3 4.2 1.4 1205K
2205K
22205K H205
H305
HE205
HE305
SR52x5
SR52x7
2
1
SN506 25 1 62 185 52 22 30 50 77 80 90 25 150 M12 15 20 22 26.5 38 4 5.4 2.15 1206K
2206K
22206K H206
H306
HE206
HE306
SR62x7
SR62x10
2
1
SN507 30 1-1/8 72 185 52 22 33 50 82 85 95 25 150 M12 15 20 24 31.5 43 4 5.4 2.35 1207K
2207K
22207K H207
H307
HE207
HE307
SR72x8
SR72x10
2
1
SN508 35 1-1/4 80 205 60 25 33 60 85 90 110 30 170 M12 15 20 26 36.5 48 4 5.4 3.2 1208K
2208K
22208K H208
H308
HE208
HE308
SR80x7.5
SR80x10
2
1
SN509
SSN509
40 1-1/2 85 205 60 25 31 60 85 90 112 30 170 M12 15 20 28 41.5 53 4 5.4 3.0
4.4
1209K
2209K
22209K H209
H309
HE209
HE309
SR85x6
SR85x8
2
1
SN510
SSN510
45 1-3/4 90 205 60 25 33 60 90 95 115 30 170 M12 15 20 28 46.5 58 4 5.4 3.75
5.0
1210K
2210K
22210K H210
H310
HE210
HE310
SR90x6.5
SR90x10
2
1
SN511
SSN511
50 2 100 255 70 28 33 70 95 100 130 35 210 M16 18 23 30 51.5 67 5 6.9 5.3
7.15
1211K
2211K
22211K H211
H311
HE211
HE311
SR100x6
SR100x8
2
1
SN512
SSN512
55 2-1/8 110 255 70 30 38 70 105 110 135 35 210 M16 18 23 32 56.5 72 5 6.9 6.3
7.95
1212K
2212K
22212K H212
H312
HE212
HE312
SR110x8
SR110x10
2
1
SN513
SSN513
60 2-1/4 120 275 80 30 43 80 110 115 150 40 230 M16 18 23 36 62 77 5 6.8 6.8
9.9
1213K
2213K
22213K H213
H313
HE213
HE313
SR120x10
SR120x12
2
1
SN515
SSN516
65 2-1/2 130 280 80 30 41 80 115 120 155 40 230 M16 18 23 38 67 82 5 6.8 7.4
9.3
1215K
2215K
22215K H215
H315
HE215
HE315
SR130x8
SR130x10
2
1
SN516
SSN516
70 2-3/4 140 315 90 32 43 95 120 125 175 50 260 M20 22 27 40 72 89 6 8.1 11.4
14.5
1216K
2216K
22216K H216
H316
HE216
HE316
SR140x8.5
SR140x10
2
1
SN517
SSN517
75 3 150 320 90 32 46 95 125 130 185 50 260 M20 22 27 42 77 94 6 8.1 11.1
15.5
1217K
2217K
22217K H217
H317
HE217
HE317
SR150x9
SR150x10
2
1
SN518
SSN518
80 3-1/4 160 345 100 35 62.4 100 145 150 195 50 290 M20 22 27 50 82 99 6 8.1 17
20.2
1218K
2218K
22218K
23218K
H218
H318
H2318
HE218
HE318
HE2318
SR160x16.2
SR160x11.2
SR160x10
2
2
1
SN519
SSN519
85   170 345 100 35 53 112 140 145 210 50 290 M20 22 27 52 87 104 6 8.1 15.5 1219K
2219K
22219K H219
H319
HE219
HE319
SR170x10.5
SR170x10
2
1
SN520
SSN520
90 3-1/2 180 380 110 40 70.3 112 160 165 218 60 320 M24 26 32 54 92 111 7 9.3 23
27.5
2220K
22220K
23220K
H320
H2320
HE320
HE2320
SR180x12.1
SR180x10
2
1
SN522
SSN522
100 4 200 410 120 45 80 125 175 180 240 70 350 M24 26 32 60 102 125 8 10.8 29
35
2222K
22222K
23222K
H322
H2322
HE322
HE2322
SR200x13.5
SR200x10
2
1
SN524
SSN524
110 4-1/4 215 410 120 45 86 140 185 190 270 70 350 M24 26 32 64 113 135 8 10.7 33.6
43.8
  22224K
23224K
H3124
H2324
HE3124
HE2324
SR215x14
SR215x10
2
1
SN526
SSN526
115 4-1/2 230 445 130 50 90 150 190 195 290 70 380 M24 28 36 64 118 140 8 10.7 41
50.4
  22226K
23226K
H3126
H2326
HE3126
HE2326
SR230x13
SR230x10
2
1
SN528
SSN528
125 5 250 500 150 50 98 150 205 210 305 80 420 M30 33 42 70 128 154 9 12.2 49
62
  22228K
23228K
H3128
H2328
HE3128
HE2328
SR250x15
SR250x10
2
1
SN530
SSN530
135 5-1/4 270 530 160 60 106 160 220 225 325 90 450 M30 33 42 76 138 164 9 12.2 60
75
  22230K
23230K
H3130
H2330
HE3130
HE2330
SR270x16.5
SR270x10
2
1
SN532
SSN532
140 5-1/2 290 550 160 60 114 170 235 240 345 90 470 M30 33 42 80 143 173 10 13.7 68.8
87
  22232K
23232K
H3132
H2332
HE3132
HE2332
SR290x17
SR290x10
2
1
